Wireless Test Systems for Automated Validation
The WTN series puts Wi-Fi and Bluetooth test stations into one instrument: four independent channels in a 19-inch, 1 HU chassis, or a single channel in a compact half-width unit. Each channel works as a Wi-Fi station, access point or monitor and as a Bluetooth device, with direct RF access through SMA ports, and every function is controlled from your test system.
Features
Independent channels
Each channel runs its own test. Start, stop and configure channels separately, from one client or several.
Station, access point, monitor
Join the device under test as a client, host an access point for it, or capture frames passively.
Measurements with timestamps
Received level per network, client, frame and chain, link parameters, throughput and connection events.
Bluetooth on every channel
Classic and Low Energy discovery, pairing, GATT and Direct Test Mode. Bluetooth 6.0 Channel Sounding as option.
Calibrated RF option
Factory calibration of output power and received level per port and band, with a calibration certificate.
Fits your test system
Python and LabVIEW instrument drivers, REST and gRPC over LAN or USB, NI TestStand and pytest support.
Models
| Model | Channels | Format | Wi-Fi | Bluetooth | Max. PHY rate |
|---|---|---|---|---|---|
| WTN-408AX | 4 | 19″, 1 HU | Wi-Fi 6E, 802.11ax | 5.2 | 2402 Mbit/s |
| WTN-408BE | 4 | 19″, 1 HU | Wi-Fi 7, 802.11be | 5.4 | 2882 Mbit/s |
| WTN-102AX | 1 | ½ 19″, 1 HU | Wi-Fi 6E, 802.11ax | 5.2 | 2402 Mbit/s |
| WTN-102BE | 1 | ½ 19″, 1 HU | Wi-Fi 7, 802.11be | 5.4 | 2882 Mbit/s |
Maximum PHY data rate per channel at 160 MHz, two spatial streams. All models share interfaces, drivers and options.
Key specifications
| Wi-Fi | |
| Standards | IEEE 802.11a/b/g/n/ac/ax; 802.11be on BE models |
|---|---|
| Frequency ranges | 2400–2483.5 MHz, 5150–5850 MHz, 5925–7125 MHz |
| Channel bandwidth | Station and monitor up to 160 MHz; access point up to 80 MHz |
| MIMO | 2 × 2, two spatial streams per channel |
| Security | Open, WPA2 and WPA3 Personal; WPA2/WPA3 Enterprise as station |
| Measurements | Received level (1 dB resolution), PHY rate, MCS, retries, noise floor, channel utilization, TCP/UDP throughput |
| Bluetooth | |
| Version | 5.2 (AX models), 5.4 (BE models); 6.0 with Channel Sounding as option |
| Functions | Classic and LE discovery, pairing, connection, GATT client and server, advertising, Direct Test Mode |
| Remote control and connectors | |
| Host interfaces | LAN 1 Gbit/s (RJ-45), 2 × USB-C (front and rear), identical command set |
| Software | Python and LabVIEW instrument drivers, REST with OpenAPI description, gRPC streaming |
| RF ports | SMA female, 50 Ω; 8 on WTN-408, 2 on WTN-102 |
| General | |
| AC supply | 100–240 V, 50/60 Hz |
| Operating temperature | 0 °C to +40 °C |
Frequency ranges and channels depend on the country of use. Full specifications are in the data sheet, available from sales.
Options and ordering
Options
- WTN-B60Bluetooth 6.0 with Channel Sounding, all channels
- WTN-CALRF calibration with factory calibration certificate
- WTN-CANCAN FD / LIN interface
- WTN-RFK2RF cable set, 2 × SMA to SMA, 1 m
- WTN-RFK8RF cable set, 8 × SMA to SMA, 1 m
- WTN-RCALRecalibration service with certificate
Applications
- Connectivity validation of infotainment, telematics and body ECUs
- Hardware-in-the-loop test systems
- Access point emulation for association, roaming and security tests
- Digital key and ranging tests with Bluetooth Channel Sounding
- Automated regression and end-of-line production test
About
SDVIO is a startup company focused on automotive electronics validation and testing.
For more details and custom solutions, please contact our sales team.
